Fan LEDs (CMIOU Chassis)

No. LED Icon Description

1 Service Required LED

(amber)

Indicates that service is required.

The fmadm faulty command provides details about any faults that

cause this indicator to light.

2 OK LED (green) Indicates these conditions:

■ Off – Fan module is not running in its normal state.

■ Steady on – Fan module is powered on and is running normally.

Related Information

■

“Checking for Faults” on page 35

■

“Interpreting LEDs” on page 44

Remove a Fan Module (CMIOU Chassis)

This procedure can be performed by a customer while the server is running if there are at least

seven operating fan modules.
