Switch Chassis Rear Components (SPARC M7-16)
No. Description Links
■
II_SWITCH_SP (switch chassis, slot IT_14)
■
II_CMIOU_SP (bottom CMIOU chassis slot, IT_5)
4
Power supplies (4), top to bottom: PS9–PS6
“Servicing Power
Supplies” on page 165
Related Information
■
“Switch Chassis Rear Components (SPARC M7-16)” on page 25
Switch Chassis Rear Components (SPARC M7-16)
Access these components from the rear of the server. These components are not part of the
chassis. You must remove these components to access the chassis.
Identifying Components 25
