Install a Switch Unit

Caution - If you remove this component while the server is powered on, wait 30 seconds before

installing the replacement component. Doing so ensures that Oracle ILOM has enough time to

detect the new component, which is required for the software to power it on.

Install the switch unit.

Servicing Switch Units 197
