Identify Disabled Components
Component Names Displayed by Diagnostic
Software
Use the information in this table to identify the name of a component that requires service.
Component Oracle ILOM Target Name Reported
Battery
/SYS/SPx/BAT
/SYS/SPPx/BAT
CMs
CMIOUs
CMPs
/SYS/CMIOUx/CM
/SYS/CMIOUx
/SYS/CMIOUx/CM/CMP
SPARC M8-8: x is 0–7
SPARC M7-8: x is 0–7
SPARC M7-16: x is 0–15
DIMMs
/SYS/CMIOUx/CM/CMP/BOByw/CHz/DIMM
SPARC M8-8: x is 0–7, y is 0–3, w is 0 or 1, z is 0 or 1
SPARC M7-8: x is 0–7, y is 0–3, w is 0 or 1, z is 0 or 1
SPARC M7-16: x is 0–15, y is 0–3, w is 0 or 1, z is 0 or 1
Fan modules (CMIOU chassis)
/SYS/FMx
Bottom CMIOU chassis: x is 0–7
Top CMIOU chassis: x is 8–15
Fan modules (switch chassis)
/SYS/SWUx/FMy
x is 0–5, y is 0–5
FPGA (CMIOU)
/SYS/CMIOUx/FPGA
SPARC M8-8: x is 0–7
SPARC M7-8: x is 0–7
SPARC M7-16: x is 0–15
FPGA (SP)
FPGA (SP) SSI links (SPARC M8-8 and
SPARC M7-8)
/SYS/SPx/FPGA
/SYS/SPx/FPGA/SSI_LINKy
x is 0 or 1, y is 0–7
FPGA (SPP)
/SYS/SPPx/FPGA
40 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
