PCIe Card Installation Order Guidelines
No. PDomain CMIOU PCIe Slot Card to Install
23.
PDomain_1 CMIOU_6 PCI2
24.
PDomain_1 CMIOU_7 PCI2
Card Installation Bottom CMIOU Chassis (SPARC
M7 With One PDomain)
For SPARC M8-8 and SPARC M7-8 servers that has one PDomain, install PCIe cards in fully
populated configurations in the order shown.
No. CMIOU PCIe Slot Card to Install
1.
CMIOU_0 PCI3
Storage card
2.
CMIOU_1 PCI3
Storage card
3.
CMIOU_2 PCI3
Network card
4.
CMIOU_4 PCI3
Network card
5.
CMIOU_5 PCI3
6.
CMIOU_6 PCI3
7.
CMIOU_0 PCI1
8.
CMIOU_1 PCI1
9.
CMIOU_2 PCI1
10.
CMIOU_4 PCI1
11.
CMIOU_5 PCI1
12.
CMIOU_6 PCI1
13.
CMIOU_3 PCI3
14.
CMIOU_7 PCI3
15.
CMIOU_3 PCI1
16.
CMIOU_7 PCI1
17.
CMIOU_0 PCI2
18.
CMIOU_1 PCI2
19.
CMIOU_2 PCI2
20.
CMIOU_3 PCI2
21.
CMIOU_4 PCI2
22.
CMIOU_5 PCI2
23.
CMIOU_6 PCI2
24.
CMIOU_7 PCI2
Servicing PCIe Cards 147
