Determine Which DIMM Is Faulty (Oracle ILOM)
■
DDR channel (CH) number (where z is 0 or 1)
This information is useful when servicing DIMMs and when assessing error messages. For
example, the following output identifies faulty DIMMs on two different SPARC M7 CMIOUs.
2013-09-06/17:16:20 ereport.hc.dev_fault@/SYS/CMIOU1/CM/CMP/BOB11/CH1/DIMM
2013-09-06/17:16:20 ereport.hc.dev_fault@/SYS/CMIOU3/CM/CMP/BOB01/CH0/DIMM
Determine Which DIMM Is Faulty (Oracle ILOM)
At the Oracle ILOM prompt, type show faulty.
The following output might be slightly different, depending on the server in use.
-> show faulty
Target | Property | Value
------------------------+----------------+----------------------
...
/SP/faultmgmt/0 | fru | /SYS/CMIOU1/CM/CMP/BOB11/CH1/DIMM
/SP/faultmgmt/0/faults/0| class | fault.memory.dimm
/SP/faultmgmt/0/faults/0| sunw-msg-id | SPSUN4V-8000-CQ
/SP/faultmgmt/0/faults/ | component | /SYS/CMIOU1/CM/CMP/BOB11/CH1/DIMM
/SP/faultmgmt/0/faults/ | uuid | 99209d8f-38ce-e9dc-95fd-c0200...
/SP/faultmgmt/0/faults/ | timestamp | 2014-09-07/13:12:35
The first line of the preceding output shows the CMIOU number, buffer chip number, and DDR
channel number. See “DIMM Names” on page 108 for information about the slot numbers
on the CMIOU.
Note - If two DIMMs are reported as faulty, replace both of the DIMMs.
Related Information
■
“Identify Faulted Components” on page 36
■
“Determine Which DIMM Is Faulty (LEDs)” on page 109
■
“DIMM Configuration Fault Messages” on page 112
Determine Which DIMM Is Faulty (LEDs)
1.
Check that the Service Required LED is lit on the front of the server.
Servicing DIMMs 109
