Remove a Switch Unit

Pull the switch unit out of the server less than halfway.

Related Information

■

“Remove a Switch Unit” on page 194

■

“Reseat a Switch Unit” on page 196

■

“Switch Chassis Cooling Zones” on page 31

Remove a Switch Unit

This procedure can be performed by a customer while the server is running.

194 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
