Unseat a Switch Unit

Note - If you are unseating a switch unit so you can replace it with a new one, ensure that you

have already removed the fan modules from the switch unit.

Pull the ejector arms out to disengage the switch unit from the server.

Press the arms back toward the unit to prevent them from being damaged.

Servicing Switch Units 193
