Remove a Switch Chassis

Adjust the height of the foot so that it rests securely on the floor.

Determine your next step:

■ If you have another person to assist you, go to Step 10.

■ If you are alone, go to Step 9.

Place a mechanical lift under the chassis, and remove the screws that fasten it to

the rack.

10.

Remove the chassis from the rack, and place it on an appropriate surface.

Related Information

■

“Install a Switch Chassis” on page 283

■

“Servicing the CMIOU Chassis” on page 269

282 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
