Remove a PCIe Card Carrier and Card From the Server
b.
Remove the carrier from the slot.
6.
Carefully remove the PCIe card from the carrier.
a.
Press the green tab to unlock the carrier latch, and open the top of the PCIe
card carrier (steps 1 and 2).
b.
Slide the card from the slot (step 3).
Caution - Avoid twisting, tilting, or pulling unevenly on the PCIe card, which could damage the
carrier slot or components on the PCIe card carrier circuit board.
7.
Place the PCIe card on a grounded antistatic mat or into its antistatic packaging.
8.
Determine your next step:
■
If you are replacing the PCIe card, go to “Install a PCIe Card Into a Card
Carrier” on page 158.
■
If you are removing the PCIe card, return the card carrier to the server.
See “Install a Card Carrier Into the Server” on page 159.
Servicing PCIe Cards 157
