Restore a PCIe Card Configuration on an I/O Domain
SUNW,qlc@0/fp/disk
SUNW,qlc@0/fp@0,0
SUNW,qlc@0,1/fp/disk
SUNW,qlc@0,1/fp@0,0/ssd@w20350080e518b846,1f
fibre-channel@0,2
fibre-channel@0,3
fibre-channel@0,4
fibre-channel@0,5
...
/SYS/CMIOU9/PCIE2/IOVFC.PF0.VF0 VF pci_45 ldg4
[pci@32d/pci@1/SUNW,qlc@0,2]
Class properties [FIBRECHANNEL]
port-wwn = 10:00:00:14:4f:f8:74:85
node-wwn = 20:00:00:14:4f:f8:74:85
bw-percent = 0
...
/SYS/CMIOU9/PCIE2/IOVFC.PF0.VF3 VF pci_45 ldg4
[pci@32d/pci@1/SUNW,qlc@0,5]
Class properties [FIBRECHANNEL]
port-wwn = 10:00:00:14:4f:fb:27:29
node-wwn = 20:00:00:14:4f:fb:27:29
bw-percent = 0
#
4.
Manually create each virtual function using the properties saved in the test file
you created.
Note - Because the system assigns virtual function names, you must create new virtual
functions in the order of the names the system assigns. For example, if four virtual functions are
created, VF0–VF3, you must create VF0 and its associated property values first so the system will
assign the properties to a virtual function with a name ending in VF0.
See “Prepare a PCIe Card For Removal” on page 151 for examples of the test file. Refer to
the Oracle VM Server for SPARC documentation for the syntax of the create-vf command.
5.
Verify that the virtual functions were created.
Note - The following example shows only an excerpt of the output.
# ldm ls-io -l pci_45
NAME TYPE BUS DOMAIN STATUS
---- ---- --- ------ ------
pci_45 BUS pci_45 primary IOV
[pci@32d]
162 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
