Install the Power Supply Shims (SPARC M8)

Note - Ensure that the arrow labeled PSU FRONT is pointing to the front of the power supply.

The ESD foam tape should be facing upward.

3.

Using a T8 driver, secure the shim to the side of the power supply with one M3

screw per shim.

Servicing Power Supplies 173
