CMIOU Chassis Rear Components

.

No. Description Links

1 Rear indicator panel (1)

This component is part of the power module.

■

Bottom CMIOU chassis: ROPNL0

“Servicing Power Modules” on page 235

22 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
