Understanding Server Cooling Zones

No. Description Link

1 Main CMIOU cooling zone “Servicing CMIOUs” on page 83

2 CMIOU power supply cooling zone “Servicing Fan Modules (CMIOU

Chassis)” on page 179 and “Servicing Power

Supplies” on page 165

Related Information

■

“Switch Chassis Cooling Zones” on page 31

30 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
