Attach an Antistatic Wrist Strap

These grounding jacks accommodate 4-mm (0.16-in.) banana plug connectors.

■ The Sun Rack II 1242 rack contains two ESD grounding jacks, one in the

front and one in the rear of the rack.

Preparing for Service 63
