Oracle SuperCluster T5-8 User Manual

Preparing for Installation
Voltage Phases Reference
High 3 Table 64, “High Voltage 3 Phase PDUs for Oracle Exadata Storage Expansion Rack,” on
page 292
TABLE 61
Low Voltage 1 Phase PDUs for Oracle Exadata Storage Expansion Rack
High Voltage One Phase Comments
kVA Size 15 kVA
Marketing part number N/A
Manufacturing part number N/A
Phase 1 ph
Voltage 200 to 240 VAC
Amps per PDU 72 A (3 inputs x 24 A)
Outlets 42 C13
6 C19
Number of inputs 3 inputs
Input current 24 A max. per input
Data center receptacle NEMA 30A/250 VAC 2-pole/3-wire L6-30P
Outlet groups per PDU 6
Usable PDU power cord length 2 m (6.6 feet) PDU power cords are 4 m long (13 feet), but
sections are used for internal routing in the
rack.
TABLE 62
Low Voltage 3 Phase PDUs for Oracle Exadata Storage Expansion Rack
High Voltage Three Phase Comments
kVA Size 14.4 kVA
Marketing part number N/A
Manufacturing part number N/A
Phase 3 ph
Voltage 190 to 220 VAC
Amps per PDU 69 A (3 inputs x 23 A)
Outlets 42 C13
6 C19
Number of inputs 2 inputs x 60 A, 3 ph
Input current 40 A max. per phase
Data center receptacle IEC 60309 60A 4-pin 250 VAC 3 ph IP 67
Outlet groups per PDU 6
Connecting Expansion Racks 291
