Parker PD-04 Series - Page 205

Parker Hannifin
P series User Guide 203
0x211C
Gain Conversion Waiting Time 1
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 1000
0
ms
RW
Yes
At all
times
Yes
Set the waiting time before conversion from gain group 1 to gain group 2.
0x211D
Gain Conversion Waiting Time 2
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 1000
0
ms
RW
Yes
At all
times
Yes
Set the waiting time before conversion from gain group 2 to gain group1.
0x211E
Dead Band for Position Control
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 1000
0
UU
RW
Yes
At all
times
Yes
During position control, the position controller output becomes 0 if the following error for
position control is under the set value.
0x211F
Drive Control Input 1
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0
-
RW
Yes
At all
times
No
The signal to the input contact of the drive can be input by the signal input through the
I/O connector as well as by setting the bit corresponding to the input. In addition, the
relevant function is activated through logical OR calculation of the signal input through
the I/O connector and the bit value under this setting.
Please see the table below for input descriptions
bit
Setting Details
0
POT
1
NOT
2
HOME
3
STOP
4
PCON
5
GAIN2
6
P_CL
7
N_CL
8
Reserved
