P series User Guide 96
2
Bit mask
UDINT
RW
No
-
Table 60. User Output Related Objects
 Physical outputs descriptions
Bit
Description
0 to 15
Reserved
16
Forced output of DO#1(I/O pin 35, 36)(0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.16) is set to 1
17
Forced output of DO#1(I/O pin 37, 38) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.17) is set to 1
18
Forced output of DO#1(I/O pin 39, 40) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.18) is set to 1
19
Forced output of DO#1(I/O pin 41, 42) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.19) is set to 1
20
Forced output of DO#1(I/O pin 43, 44) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.20) is set to 1
21
Forced output of DO#1(I/O pin 45, 46) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.21) is set to 1
22
Forced output of DO#1(I/O pin 47, 48) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.22) is set to 1
23
Forced output of DO#1(I/O pin 49, 50) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.23) is set to 1
24
DO #1output status (0:OFF, 1:ON)
25
DO #2output status (0:OFF, 1:ON)
26
DO #3 output status (0:OFF, 1:ON)
27
DO #4output status (0:OFF, 1:ON)
28
DO #5output status (0:OFF, 1:ON)
29
DO #6output status (0:OFF, 1:ON)
30
DO #7output status (0:OFF, 1:ON)
31
DO #8output status (0:OFF, 1:ON)
Table 61. Physical Output Descriptions
 Bit mask descriptions
Bit
Descriptions
0 to 15
Reserved
16
DO#1(I/O pin 35, 36)output status setting (0:Disable, 1:Enable)
17
DO#2(I/O pin 37, 38)output status setting (0:Disable, 1:Enable)
18
DO #3(I/O pin 39, 40)output status setting (0:Disable, 1:Enable)
19
DO #4(I/O pin 41, 42)output status setting (0:Disable, 1:Enable)
20
DO#1(I/O pin 43, 44)output status setting (0:Disable, 1:Enable)
21
DO#2(I/O pin 45, 46)output status setting (0:Disable, 1:Enable)
22
DO #3(I/O pin 47, 48)output status setting (0:Disable, 1:Enable)
23
DO #4(I/O pin 49, 50)output status setting (0:Disable, 1:Enable)
24 to 31
Reserved
Table 62. Bit Mask Descriptions
