 PM-FExxAMxx Series Features
Motor Output Power
PM-
FE09AMxx
PM-
FE15AMxx
PM-
FE22AMxx
PM-
FE30AMxx
Rated Output Power
900 Watts
1500 Watts
2200 Watts
3000 Watts
Rated Torque
N-m
2.86
4.77
7.00
9.55
kgf-cm
29.20
48.70
71.40
97.40
Instantaneous Peak
Torque
N-m
8.59
14.32
21.01
28.65
kgf-cm
87.70
146.10
214.30
292.20
Rated Speed
3000 rpm
Peak Speed
5000 rpm
Moment of Inertia
kg-m
2
x 10
-4
5.66
10.18
14.62
19.04
gf-cm-s
2
5.77
10.39
14.92
19.43
Available Moment of Load Inertia
Motor Inertia x 10
Position Feedback
BiSS Interface – 19bit
Weight
5.0kg
6.7kg
8.5kg
10.1kg
Standards
CE
Temperature
0 - 40 ˚ C
Humidity
20-80% non-condensing
Shock / Vibration
5G (49m/s
2
)
Table 114. PM-FExxAMxx Series Features
 PM-FExxDMxx Series Features
Motor Output Power
PM-
FE06DMxx
PM-
FE11DMxx
PM-
FE16DMxx
PM-
FE22DMxx
Rated Output Power
600 Watts
1100 Watts
1600 Watts
2200 Watts
Rated Torque
N-m
2.86
5.25
7.63
10.50
kgf-cm
29.20
53.60
77.90
107.10
Instantaneous Peak
Torque
N-m
8.59
15.75
22.92
31.51
kgf-cm
87.70
160.70
233.80
321.40
Rated Speed
2000 rpm
Peak Speed
3000 rpm
Moment of Inertia
kg-m
2
x 10
-4
5.66
10.18
14.62
19.04
gf-cm-s
2
5.77
10.39
14.92
19.43
Available Moment of Load Inertia
Motor Inertia x 10
Position Feedback
BiSS Interface – 19bit
Weight
5.0kg
6.7kg
8.5kg
10.1kg
Standards
CE
Temperature
0 - 40 ˚ C
Humidity
20-80% non-condensing
Shock / Vibration
5G (49m/s
2
)
Table 115. PM-FExxDMxx Series Features
