P series User Guide 259
 PM-FExxGMxx Series Features
Motor Output Power
PM-
FE05GMxx
PM-
FE09GMxx
PM-
FE13GMxx
PM-
FE17GMxx
Rated Output Power
450 Watts
850 Watts
1300 Watts
1700 Watts
Rated Torque
N-m
2.86
5.41
8.27
10.82
kgf-cm
29.22
55.19
84.41
110.38
Instantaneous Peak
Torque
N-m
8.59
16.23
24.82
32.46
kgf-cm
87.66
165.57
253.23
331.14
Rated Speed
1500 rpm
Peak Speed
3000 rpm
Moment of Inertia
kg-m
2
x 10
-4
5.66
10.18
14.62
19.04
gf-cm-s
2
5.77
10.39
14.92
19.43
Available Moment of Load Inertia
Motor Inertia x 10
Position Feedback
BiSS Interface – 19bit
Weight
5.0kg
6.7kg
8.5kg
10.1kg
Standards
CE
Temperature
0 - 40 ˚ C
Humidity
20-80% non-condensing
Shock / Vibration
5G (49m/s
2
)
Table 116. PM-FExxGMxx Series Features
 PM-FExxMMxx Series Features
Motor Output Power
PM-
FE03MMxx
PM-
FE06MMxx
PM-
FE09MMxx
PM-
FE12MMxx
Rated Output Power
300 Watts
600 Watts
900 Watts
1200 Watts
Rated Torque
N-m
2.86
5.72
8.59
11.46
kgf-cm
29.22
58.40
57.70
116.90
Instantaneous Peak
Torque
N-m
8.59
17.18
25.77
34.22
kgf-cm
87.66
175.30
262.90
349.10
Rated Speed
1000 rpm
Peak Speed
2000 rpm
Moment of Inertia
kg-m
2
x 10
-4
5.66
10.18
14.62
19.04
gf-cm-s
2
5.77
10.39
14.92
19.43
Available Moment of Load Inertia
Motor Inertia x 10
Position Feedback
BiSS Interface – 19bit
Weight
5.0kg
6.7kg
8.5kg
10.1kg
Standards
CE
Temperature
0 - 40 ˚ C
Humidity
20-80% non-condensing
Shock / Vibration
5G (49m/s
2
)
Table 117. PM-FExxMMxx Series Features
