 PM-FFxxAM/MMxx Series Features
Motor Output Power
PM-
FF30AMxx
PM-
FF12MMxx
PM-
FF20MMxx
PM-
FF30MMxx
Rated Output Power
3000 Watts
1200 Watts
2000 Watts
3000 Watts
Rated Torque
N-m
9.55
11.46
19.09
28.64
kgf-cm
97.40
194.8
292.2
428.7
Instantaneous Peak
Torque
N-m
28.65
57.29
85.94
126.1
kgf-cm
292.3
584.40
876.60
128.60
Rated Speed
3000 rpm
1000rpm
Peak Speed
5000 rpm
2000rpm
1700rpm
Moment of Inertia
kg-m
2
x 10
-4
27.96
27.96
46.56
73.85
gf-cm-s
2
28.53
28.53
47.51
75.36
Available Moment of Load Inertia
Motor Inertia x 5
Position Feedback
BiSS Interface – 19bit
Weight
12.5kg
12.5kg
17.4kg
25.2kg
Standards
CE
Temperature
0 - 40 ˚ C
Humidity
20-80% non-condensing
Shock / Vibration
5G (49m/s
2
)
Table 118. PM-FFxxAM/MMxx Series Features
 PM-FFxxDM/GMxx Series Features
Motor Output Power
PM-
FF22DMxx
PM-
FF35DMxx
PM-
FF20GMxx
PM-
FF30GMxx
Rated Output Power
2200 Watts
3500 Watts
1800 Watts
2900 Watts
Rated Torque
N-m
10.50
16.70
11.45
18.46
kgf-cm
107.10
170.40
116.9
188.3
Instantaneous Peak
Torque
N-m
31.50
50.10
34.35
55.38
kgf-cm
321.30
511.40
350.60
564.90
Rated Speed
2000 rpm
1500rpm
Peak Speed
3000rpm
2700rpm
Moment of Inertia
kg-m
2
x 10
-4
27.96
46.56
27.96
46.56
gf-cm-s
2
28.53
47.51
28.53
47.51
Available Moment of Load Inertia
Motor Inertia x 5
Position Feedback
BiSS Interface – 19bit
Weight
12.5kg
17.4kg
12.5kg
17.4kg
Standards
CE
Temperature
0 - 40 ˚ C
Humidity
20-80% non-condensing
Shock / Vibration
5G (49m/s
2
)
Table 119. PM-FFxxDM/GMxx Series Features
