P series User Guide 253
Provided that the relevant bit mask (0x60FE:02.21) is set to
1
22
Forced output of DO#1(I/O pin 47, 48) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.22) is set to
1
23
Forced output of DO#1(I/O pin 49, 50) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.23) is set to
1
24
DO #1output status (0:OFF, 1:ON)
25
DO #2output status (0:OFF, 1:ON)
26
DO #3 output status (0:OFF, 1:ON)
27
DO #4output status (0:OFF, 1:ON)
28
DO #5output status (0:OFF, 1:ON)
29
DO #6output status (0:OFF, 1:ON)
30
DO #7output status (0:OFF, 1:ON)
31
DO #8output status (0:OFF, 1:ON)
Table 107. Physical Output Descriptions
 Bit mask Descriptions
bit
Descriptions
0 to 15
Reserved
16
DO#1(I/O pin 35, 36) output status setting (0:Disable,
1:Enable)
17
DO#2(I/O pin 37, 38) output status setting (0:Disable,
1:Enable)
18
DO #3(I/O pin 39, 40)output status setting (0:Disable,
1:Enable)
19
DO #4(I/O pin 41, 42)output status setting (0:Disable,
1:Enable)
20
DO#1(I/O pin 43, 44) output status setting (0:Disable,
1:Enable)
21
DO#2(I/O pin 45, 46) output status setting (0:Disable,
1:Enable)
22
DO #3(I/O pin 47, 48)output status setting (0:Disable,
1:Enable)
23
DO #4(I/O pin 49, 50)output status setting (0:Disable,
1:Enable)
24 to 31
Reserved
Table 108. Bit Mask Descriptions
0x60FF
Target Speed
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
DINT
–2147483648 to
2147483647
0
UU/s
RW
Yes
At all
times
No
Set the target speed at PV mode and CSV mode.
