Page #90 background image
Parker Hannifin
P series User Guide 88
Table 55. Allocating Digital Input Related Objects
You can set the functions of digital input signal of I/O connector and input signal level.
Choose the signals to allocate with bit 7~0, and set the signal level at bit 15.
Set
Value
Allocated
Signal
Set
Value
Allocated
Signal
0x00
Not allocated
0x11
PAUSE
0x01
POT
0x12
REGT
0x02
NOT
0x13
HSTART
0x03
HOME
0x14
ISEL0
0x04
STOP
0x15
ISEL1
0x05
PCON
0x16
ISEL2
0x06
GAIN2
0x17
ISEL3
0x07
P_CL
0x18
ISEL4
0x08
N_CL
0x19
ISEL5
0x09
PROBE1
0x1A
ABSRQ
0x0A
PROBE2
0x1B
JSTART
0x0B
EMG
0x1C
JDIR
0x0C
A_RST
0x1D
PCLR
0x0F
SV_ON
0x1E
AOVR
0x10
START
Example) When the set value is 0x0006.
0
0
0
6
CONTACT A
GAIN2Allocation
Contact A: Base status is 0(Low). Activates when 1(High) is input.(Active High)
Contact B: Base status is 1(High). Activates when 0(Low) is input (Active Low)
BIT
Details
15
Signal input level setting
(0:CONTACT A,
1:CONTACT B)
14~8
Reserved
7~0
Input signal allocated
