P series User Guide 36
3.4 Multiple Drive Installations
3.4.1 Drive Node Address Setting
You can set the address of the drive‘s nodes. You can confirm the set addresses at
node ID (0x2003). The value of the node switch is read only once when the power is
turned on. The set value changed after that point applies when the power is turned on
again next time.
The node switch of this drive consists of a rotary switch capable of setting values
from 0 to 15 (F) and toggle switches that can be turned On or Off. In total, you can set
node addresses from 0 to 31.
2
3
6
8
9
E
D
B
0
1
F
4
5
7
A
C
Rotary switch
setting
0
1
2
3
4
5
6
7
8
9
A
Toggle switch
setting
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Node address
0
1
2
3
4
5
6
7
8
9
10
Rotary switch
setting
B
C
D
E
F
0
1
2
3
4
5
Toggle switch
setting
OFF
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
ON
Node address
11
12
13
14
15
16
17
18
19
20
21
Rotary switch
setting
6
7
8
9
A
B
C
D
E
F
Toggle switch
setting
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
Node address
22
23
24
25
26
27
28
29
30
31
Table 12. Drive Node Address Setting
