P series User Guide 206
 I/O Configuration(0x2200~ )
0x2200
Digital Input Signal 1 Selection
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0x000F
-
RW
No
Power
Resupply
Yes
Set the function of I/O connector‘s digital input signal 1 and input signal level.
Example) when the set value is 0x006
0
0
0
6
CONTACT
A
GAIN2Allocation
0x2201
Digital Input Signal 2 Selection
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0x0001
-
RW
No
Power
Resupply
Yes
Set
Value
Allocation
signal
0x00
Not allocated
0x01
POT
0x02
NOT
0x03
HOME
0x04
STOP
0x05
PCON
0x06
GAIN2
0x07
P_CL
0x08
N_CL
0x09
PROBE1
0x0A
PROBE2
0x0B
EMG
0x0C
A_RST
0x0F
SV_ON
0x10
START
0x11
PAUSE
0x12
REGT
0x13
HSTART
0x14
ISEL0
0x15
ISEL1
0x16
ISEL2
0x17
ISEL3
0x18
ISEL4
0x19
ISEL5
0x1A
ABSRQ
0x1B
JSTART
0x1C
JDIR
0x1D
PCLR
0x1E
AOVR
bit
Setting Details
15
Signal input level
setting(0:CONTACT A,
1:CONTACT B)
14~8
Reserved
7~0
Input signal allocation
