P series User Guide 51
 Please use the product by connecting shorting pins to the drive‘s B, BI
terminals. And when using an external recovery resistance, please connect
with the B+, B terminals after removing the shorting pin, at the standard
resistance.
Type
Resistance
Standard
Capacity
* Notes
100[W]
100[Ω]
Internal 50[W]
Caution
Please see ― 3.6.2 External Resistor
Setting ‖ for resistance values when
expanding recovery capacity.
200[W]
400[W]
800[W]
40[Ω]
Internal
100[W]
1[kW]
2[kW]
13[Ω]
Internal
150[W]
3.5[kW]
 Please construct the system so that the main power (L1, L2, L3) is always
supplied after the control power (C1, C2) is supplied (see ― 3.2 System
Installation Overview ‖)
 High voltage remains even after the main power is shut off. Please exercise
caution.
 The length of the earth cable should be as short as possible. Too long cables
may cause noises that might cause malfunction.
Warning
Connecting excessive voltage will damage the drive.
Caution
Start re-wiring after making sure that the charge lamp is off after shutting off the main
power, to avoid being electrocuted.
