Test and Inspection Matrix 5: Performance Verification
155
Defibrillator
Test — AC
Power (DA)
(if AC Power
used in
normal
operation)
Using only AC power and a defibrillator
analyzer, run the “Defibrillator Test (AC
Power at 200 J)” on page 165.
If all checks pass, and all data within limits: DA:x
Example DA:p
Energy measured by analyzer:
Delivered into 50-ohm test load 200 ± 20 J
Setting displayed by Efficia DFM100: 200 J
Delivered energy Actual delivered energy ± 10%
then Defibrillator Measurement test passes
Defibrillator
Tes t —
Battery Power
(DB)
Using only battery power and a
defibrillator analyzer, run the
“Defibrillator Test (Battery Power at
200 J)” on page 166):
If all checks pass, and all data within limits: DB:x
Example DB:p
Energy measured by analyzer:
Delivered into 50-ohm test load 200 ± 20 J
Setting displayed by Efficia DFM100: 200 J
Delivered energy Actual delivered energy ± 10%
then Defibrillator Measurement test passes.
Defibrillator
Disarm Test
(D)
Run the “Defibrillator Charge
Cancellation Test” on page 167.
Verify that the device is disarmed
Verify that the charge tone stopped
then the Defibrillator Disarm test passes.
D:x
Example D:p
Paddles Safety
Check (Pa)
Perform “Paddles Safety Check” on
page 168.
If PCI flashes as expected, then Paddles test
passes.
Pa:x
Example Pa:p
Safety Tests Using a Safety Analyzer
NOTE: All leakage current tests include both Normal and Reverse Polarity Conditions. Report worst case values.
Protective
Earth
Resistance
(S1)
Protective Earth Resistance. See
“Protective Earth Resistance” on page 170
— aaa
Maximum Impedance:
<
100 m
S1:x/aaa/
Example:
S1:p/80
AC Mains
(S2)
Earth Leakage Current NC (Normal
Condition). See “AC Mains (Ground
Leakage)” on page 171 — bbb
If Normal Condition Maximum leakage
current:
<
300 A (UL, 120 VAC)
<
500 A (IEC, 240 VAC)
S2:x/bbb/cccc
Example:
S2:p/125/800
Earth Leakage Current
SF (Single Fault, open neutral) — cccc
If Single Fault Maximum leakage current:
<
1000 A,
then Earth Leakage Safety test passes
Table 33 Test and Inspection Matrix (Continued)
Tes t Gr o up
Name
Test or Inspection to Perform Expected Test Results Data to Record
x = p (pass)
or f (fail)
