5: Performance Verification Test and Inspection Matrix
156
NOTE: When recording test results, separate results within a test by slashes (/); separate tests by semicolons (;);
and use no empty spaces.
V:x;OC:x;EL:x;C:x;DP:x;Pr:x;NC:x;E:x;SP:x;NM:x;SC:x;P:x;DA:x;DB:x;D:x;Pa:x;
S1:x/aaa;S2:x/bbb/cccc;S3:x/dd/eee;S4:x/ff/gg/hh/ii/jj/kk/ll/mm/nn/ooo/ppp/qqq
For example: V:p;OC:p;EL:p;C:p;DP:p;Pr:p;NC:p;E:p;SP:p;NM:p;SC:p;P:p;DA:p;DB:p;D:p;Pa:p;
S1:p/80; S2:p/125/800; S3:p/99/299;S4:p/9/49/49/9/49/49/9/49/49/99/499/499
Chassis
Leakage (S3)
Use ECG Out (Sync) jack as ground NC
(Normal Condition). See “Chassis
(Enclosure) Leakage” on page 171 — dd
If Normal Condition Maximum leakage
current:
< 100 A
S3:x/dd/eee
Example:
S3:p/99/299
Single Fault condition
— eee
If Single Fault Maximum leakage current:
< 300 A (UL)
< 500 A (IEC)
then Chassis Leakage test passes.
Patient Lead
Leakage (S4)
ECG Patient Cable (see “Patient Lead
Leakage” on page 171).
• Source (Normal Condition) — ff
• Source (Single Fault condition — open
earth, open neutral) — gg
• With Mains on applied part (Single
Fault condition) — hh
If readings are as expected:
•<
10 A
•<
50 A
•<
50 A
then ECG Cable Leakage test passes.
S4: x/ff/gg/hh
/ii/jj/kk/ll/mm/n
n/ooo/ppp/qqq
Example:
S4:p/9/49/49/
9/49/49/
9/49/49/
99/499/499
Pads Cable
• Source (Normal Condition) — ii
• Source (Single Fault Condition — open
earth, open neutral) — jj
• With Mains on applied part (Single
Fault condition) — kk
If readings are as expected:
•<
10 A
•<
50 A
•<
50 A
then Pads Cable Leakage test passes
SpO
2
Cable
• Source (Normal Condition) — ll
• Source (Single Fault Condition — open
earth, open neutral) — mm
• With Mains on applied part (Single
Fault condition) — nn
If readings are as expected:
•<
10 A
•<
50 A
•<
50 A
then SpO
2
Cable Leakage test passes
Paddles Cable
• Source (Normal Condition) — ooo
• Source (Single Fault Condition — open
earth, open neutral) — ppp
• With Mains on applied part (Single
Fault condition) — qqq
If readings are as expected:
•<
100 A
•<
500 A
•<
500 A
then Paddles Cable Leakage test passes
Table 33 Test and Inspection Matrix (Continued)
Tes t Gr o up
Name
Test or Inspection to Perform Expected Test Results Data to Record
x = p (pass)
or f (fail)
