Performance Verification Procedures 5: Performance Verification
175
Figure 138 Efficia DFM100 Insulation Resistance Test Diagram - F-Type Applied
Parts and Protective Earth
Figure 139 Efficia DFM100 Insulation Resistance Test Diagram - F-Type Applied
Parts and Non-Earthed Accessible Conductive Parts
Table 34 Acceptable Test Results
Figure Class I
135 2 M Ohms
136 M Ohms
137 M Ohms
138 M Ohms
139 M Ohms
To Next Page
