37 Default Settings Appendix

448

CO2 Default Settings

CCO High Limit 8.5 l/min 3.7 l/min 1.3 l/min

CCO Low Limit 4.0 l/min 2.6 l/min 0.3 l/min

CCI

Alarms On On On

CCI High Limit 4.3 l/min/m2 4.3 l/min/m2 5.2 l/min/m2

CCI Low Limit 2.0 l/min/m2 2.6 l/min/m2 1.2 l/min/m2

Settings

Factory defaults H10/H20/H40 H30 (deviations from H10/H20/H40)

Adult Pedi Neo Adult Pedi Neo

etCO₂ Low 30 30 30 25 25 25

etCO₂ High 50 50 50 60 60 60

imCO₂ High 444

CO₂ Alarms On On On

Unit mmHg mmHg mmHg

Scale 40mmHg40mmHg40mmHg50 50 50

imCO₂ On On On Off Off Off

N₂O Corr. (only

M3015A/M3016A)

Off Off Off

Oxygen Corr. (only

M3014A)

16% 16% 16%

Gas Corr. (only

M3014A)

Off Off Off

Humidity Corr.BTPSBTPSBTPS

Max Hold Off Off Off

awRR On On On

awRR Alarms On On On

High Limit (awRR) 30 30 60

Low Limit (awRR)8830

Apnea Time 20 sec 20 sec 20 sec

Color Yellow Yellow Yellow White White White
