The Patient Session
3-34 ST80i Stress Test System Instructions for Use
Rhythm Print
You can print a continuous rhythm strip directly from the ST80i screen at any point during the
test. The system generates a continuous report (configurable from 1 to 12 leads) of the leads
specified in the configuration for the particular profile. For details, see the ST80i Installation
and Configuration Guide.
The continuous rhythm strip contains the patient's name and the current date and time. You
can generate continuous rhythm strips during all phases of a test.
Any scheduled automatic 12-lead or manually generated events that occur during continuous
rhythm printing are saved for later review or printing and are included in the final report.
To change the settings for Rhythm Printing before printing the Rhythm Strip
1
Use the Page icon to set the top of the page
2 Use the Gear/Quick Settings icon [Gear/Quick Settings Rhythm Print] to set the
Leads, Limb Gain, Chest Gain, and Speed.
To print a continuous strip
1
Click the Rhythm Print icon.
A continuous Rhythm Strip will print.
2 Click the Rhythm Print icon again to stop the strip from printing.
12-Leads Print
The timed printing of the 12-Lead ECG is based on the Exercise Protocol settings that are
preconfigured on the Config screen’s
Exercise Protocol tab. For details, see the ST80i
Installation and Configuration Guide.
In addition to the timed printing of an ECG, you can also generate 12-lead ECGs during all
phases of the test. Select this icon if you want to print a 12-lead ECG in real time.
NOTE 12-Lead ECG also prints when an Event or RPE is recorded. The ECG also includes pacemaker
detection as well as arrhythmia notification, if enabled.
To print a real-time 12-Lead ECG
Click the 12-Leads Print icon.
A 12-Lead ECG will print.
