Specifications and Requirements
E-6 ST80i Stress Test System Instructions for Use
ST80i Thermal Printer Specifications
Table E-4 ST80i thermal printer specification
Feature Specification
Instrument type
Thermal printer
Paper type
Supports the use of the following paper types supplied as
z-fold in packages of 100 and 200 sheets:
A-size Normal, Anti-fade, and Easy Tear
A4-size Normal, Anti-fade, thin, and Easy Tear
Recording technique
Computer controlled, thermal dot array
Print-head width
8.5 inches (216 mm)
Print-head resolution
Vertical: 200 dots/inch, vertical
Horizontal:
5, 10, and 25 mm/sec: 500 dots/inch
50 mm/sec: 250 dots/inch
Printer speeds
25 or 50 mm/sec for AUTO report
5, 10, 25, or 50 mm/sec for rhythm print
External ports and data
interfaces
USB 2.0-compliant, type-B socket connector
Chassis leakage current
Meet or exceed requirements of ANSI/AAMI EC11
Power
100-240 VAC at 50/60 Hz
Weight
9 pounds
Dimensions H x W x D
8 cm x 48 cm x 30 cm maximum
