The Patient Session
3-46 ST80i Stress Test System Instructions for Use
Maximum ST changes in this stage (for Stage printout only)
Current ST change (for Stage printout only)
Continuous Rhythm Strip
You can trigger continuous rhythm printing using the Rhythm Print button on the Exercise
screen. You can also turn off continuous printing by using the same
Rhythm Print button.
Before using the Rhythm Print option, you can:
ST80i software automatically advances the paper to the page header
You can adjust Rhythm Print settings using the Gear (Quick Settings) icon
To print a continuous Rhythm Strip
1
Click the Gear (Quick Settings) icon; select the Rhythm Print tab.
2 Adjust the settings, if applicable, for:
– Leads (Select the leads you want to print)
– Limb Gain (options include: 2.5 mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV)
– Chest Gain (options include Full, Half)
– Speed (options include 5 mm/s, 10 mm/s, 25 mm/s, 50 mm/s)
3 Click the Rhythm Print icon
4 To end the printing, click the Rhythm Print icon again.
De-Identification
When printing patient reports, you can de-identify the study to be in HIPAA compliance. This
option hides all patient identification information from the study printout so that the identity of
the patient is protected.
This option is preconfigured in the Settings section of the application.
To de-identify a patient
1
Click Settings on the Main Screen.
2 Select the System Settings tab
3 Select the System option
4 Place a checkmark in the “De-identify Patient Information on Report” box
5 Click Save.
Proceed to “Ending the Patient Session,” which follows.
