The Patient Session
3-44 ST80i Stress Test System Instructions for Use
Print Options
ST80i supports several print options during the stress test, including:
 Real-time ECG
 Resting 12-Lead ECG report (with interpretation) – interpretion is printed only during Pre
Exercise phase when an event is selected
 Stage printout (without interpretation)
 Event printout (without interpretation)
 Real-time rhythm printing
Real-Time ECG
Any time during the testing, you can print a real-time 12-Lead ECG from the Exercise screen.
You can trigger a real-time ECG using the 12 Lead Print button on the screen. The time
latency should be less than 7 seconds.
To print a real-time ECG
 Click the 12 Lead Print button on the Procedure bar.
12-Lead Resting ECG Report
Before the formal stress testing starts, or after the stress testing completes, you can print a
12-Lead resting ECG report.
The 12-Lead Resting ECG is printed according to the user profile settings. Resting ECG
measurement and interpretation is included as part of a 12-Lead ECG Report.
 Report Title
 Patient Demographic
 Study Information
 Interpretation of 12-Lead ECG statement
 12x1, 6x2, 3x4, 3x4 3R display
To print a 12-Lead Resting ECG Report
 Click the 12 Leads Print button on the Procedure bar.
For more information on printing reports, see “Working with Reports” on page 4-1.
