An Overview of the ST80i Stress Test System
2-18 ST80i Stress Test System Instructions for Use
Waveform
Real-time ECG analysis employs the latest C-Alg analysis to calculate an adult patient's ECG
for ST segment (elevation or depression) and to produce events and notifications
simultaneously for all supported ECG leads.
The real-time waveform default is the 12-Lead. You can choose from four display formats for
the real-time ECG:
12 Leads
6 x 2 Leads
6 Leads
3 Leads
To change the real-time ECG format
1
Click the Waveform icon.
2 Select which lead configuration you want to display from the drop-down menu:
– 12 Leads
– 6 x 2 Leads
–6 Leads
–3 Leads
The Waveform screen display changes to the new setting.
Hide/Show View
To allow maximum viewing of the waveforms, some views are hidden. Use the Hide/Show
View
icon to display the following:
Gear Quick Settings:
Filter (LP, HP, AC, Artifact, Smart)
Display (Limb Gain, Chest Gain, Speed)
Rhythm Print (Leads, Limb Gain, Chest Gain, Speed)
Sync Out (Analog Out 1 – Amplify Ratio; Analog Out 2 – Amplify
Ratio; TTL Out – Polarity, Duration)
Table 2-5 Toolbar Icons
Icon Description
