The Patient Session
3-38 ST80i Stress Test System Instructions for Use
During the Recovery phase:
The system automatically prints a 12-lead ECG. The 12-lead ECG is printed at this stage
transition regardless of system settings.
The total exercise time clock freezes.
ST80i advances the treadmill or ergometer to the recovery workloads specified in the
protocol.
Select Stop Treadmill to stop the Treadmill. (You can also select the End button)
Using the Notes icon, you can enter comments describing why the patient ended the
Exercise phase of the test, the patient’s symptoms, and conclusions.
Figure 3-15 Recovery Phase Screen
To end the Recovery phase
1
Click the Report button.
A message displays: “Confirm End of Study. The data will be saved.”
2 Click OK. You also have the option to cancel.
The message “Loading” is displayed.
The Report screen is displayed.
