Report Screen
ST80i Stress Test System Instructions for Use 4-5
Figure 4-1 ST80i Report Screen
Table 4-1 ST80i Report Screen Features
Feature Description
A
Title Bar - where you enter or update patient information in the Patient
Demographics window.
B
Procedure Bar - [Report, Status: Complete or Incomplete] and buttons:
Change J+ , Save, Export, Print, Confirm, Replay
C
Report Tabs Summary, Tabular, Trend Graph, Averages, Events, Resting ECG,
Full Disclose
D
Real-time 7.5-second ECG by selected lead (ECG for one lead is displayed in
the lower left section of the screen; use the Change Lead drop-down arrow to
change selected lead)
E
Two print options for the current ECG lead: Print 12-Lead ECG Report;
Start Rhythm Printing
F
Current Blood Pressure – shows current blood pressure of the patient
