LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Printer Assembly/Interface PCB Cable (W16) Replacement
Section Menu Section Contents Procedures Back Index
222
8
Installing the Printer Assembly/Interface PCB Cable (W16)
Refer to Figure 8.30 on p. 221.
To install the printer/interface PCB cable (W16) into the front case:
NOTE: When installing printer/interface PCB cable (3009724-001) use External Hardware Repair Kit (MIN 3305431-016) (p.
507).
1. Install a new rubber moisture gasket (3006809-00) onto the W16 cable. Connect the W16 cable to the printer assembly at J40.
Place the printer assembly connector bracket (3006810-01) over the printer W16 cable and secure it with one new screw with
washer (3207337-312) into the front case; torque to 6.8 in-lb.
2. Connect the W19 cable ground terminal (3009726-03) to the printer assembly connector bracket.
3. If interface PCB is present, connect the W16 cable to the interface PCB at J35.
4. Reassemble the case as described in Reassembling the Case (p. 184).
