LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Speaker Assembly (W17) Replacement
Section Menu Section Contents Procedures Back Index
225
8
Installing the Speaker Assembly (W17)
Refer to Figure 8.31 on p. 223.
To install the Speaker Assembly into the front case (Inside Front Case Diagram (p. 189)):
NOTE: When installing speaker assembly (3009726-03) use External Hardware Repair Kit (MIN 3305431-016) (p. 507).
1. Set the Speaker Assembly into the case and secure the spring clamp (3012693-00) with one new screw with washer (3207337-
312); torque to 6.8 in-lb.
NOTE: Make sure you do not pinch the wires during reassembly.
2. If interface PCB is present, connect the Speaker Assembly to the interface PCB at J34.
3. Reassemble the case as described in Reassembling the Case (p. 184).
CAUTION
POSSIBLE MOISTURE LEAKAGE When installing the Speaker Assembly, make sure
the speaker felt moisture barrier is in place on the front case to help prevent ingress of
fluids. When replacing the speaker, do not touch the speaker felt.
