LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
CO2 Inlet Connector Cable (W28) Replacement
Section Menu Section Contents Back Index
352
8
Installing the CO2 Inlet Connector Cable (W28)
 To install the CO2 inlet connector cable:
NOTE: When replacing the CO2 inlet connector cable assembly, use CO2 Connector Repair Kit (MIN 3305431-014) (p. 506).
1. Set the CO2 connector adapter (3012119-02) in place on the face of the new bezel.
2. Place the new CO2 connector retainer (3012121-002) and new seal (3007997-01) in place on the underside of the bezel and
tighten together with four new screws (202253-732); torque to 2.0 in-lb using a P0 bit.
3. Slide the CO2 inlet connector cable (W28) (3012140-008) into the new CO2 connector retainer.
4. Install the parameter bezel as described in Installing the Parameter Bezel (p. 313).
5. Install the system/therapy PCB assembly as described in Installing the System (A01)/Therapy (A04) PCB Assembly (p. 239).
6. Reassemble the case as described in Reassembling the Case (p. 184).
CAUTION
POSSIBLE MOISTURE LEAKAGE When installing the W28 cable, apply 2 in-lb of
torque when installing the screw retaining the W28 cable to help prevent ingress of
fluids.
