User’s Manual of WGSD-10020 Series
36
 Approved PLANET SFP Transceivers
PLANET Managed Switch supports both Single mode and Multi-mode SFP transceiver. The following list of approved PLANET
SFP transceivers is correct at the time of publication:
Gigabit SFP Transceiver modules
 MGB-GT SFP-Port 1000Base-T Module
 MGB-SX SFP-Port 1000Base-SX mini-GBIC module
 MGB-LX SFP-Port 1000Base-LX mini-GBIC module
 MGB-L50 SFP-Port 1000Base-LX mini-GBIC module -50KM
 MGB-L70 SFP-Port 1000Base-LX mini-GBIC module -70KM
 MGB-L120 SFP-Port 1000Base-LX mini-GBIC module -120KM
 MGB-LA10 SFP-Port 1000Base-LX (WDM,TX:1310nm) -10KM
 MGB-LA20 SFP-Port 1000Base-LX (WDM,TX:1310nm) -20KM
 MGB-LB20 SFP-Port 1000Base-LX (WDM,TX:1550nm) -20KM
 MGB-LA40 SFP-Port 1000Base-LX (WDM,TX:1310nm) -40KM
 MGB-LB40 SFP-Port 1000Base-LX (WDM,TX:1550nm) -40KM
Fast Ethernet SFP Transceiver modules
 MFB-FX SFP-Port 100Base-FX Transceiver -2KM
 MFB-F20 SFP-Port 100Base-FX Transceiver -20KM
 MFB-F60 SFP-Port 100Base-FX Transceiver -60KM
 MFB-FA20 SFP-Port 100Base-BX Transceiver (WDM,TX:1310nm) -20KM
 MFB-FB20 SFP-Port 100Base-BX Transceiver (WDM,TX:1550nm) -20KM
It recommends using PLANET SFPs on the Managed
Switch. If you insert a SFP transceiver that is
not supported, the Managed Switch will not recognize it.
Before connect the other Managed Switches, workstation or Media Converter.
1. Make sure both side of the SFP transceiver are with the same media type, for example: 1000Base-SX to 1000Base-SX,
1000Bas-LX to 1000Base-LX.
2. Check the fiber-optic cable type match the SFP transceiver model.
 To connect to 1000Base-SX SFP transceiver, use the Multi-mode fiber cable- with one side must be male duplex LC
connector type.
 To connect to 1000Base-LX SFP transceiver, use the Single-mode fiber cable-with one side must be male duplex LC
connector type.
 Connect the fiber cable
1. Attach the duplex LC connector on the network cable into the SFP transceiver.
2. Connect the other end of the cable to a device – switches with SFP installed, fiber NIC on a workstation or a Media
