Planmeca Compact I User Manual

Chapter C - SERVICE MODE
Planmeca Compact i C-15
GENERAL ABOUT THE SERVICE MODE
Technical Manual
n.205 Lifter height calibration in millimetres (mm) C-45
n.206 Backrest angle calibration in degrees (deg) C-45
n 207 Headrest length in millimetres (mm) in relation to calibra-
tion point and virtual origo point
C-46
n 208 Headrest height in millimetres (mm) in relation to back-
rest zero-level and virtual origo point
C-46
n 209 Headrest angle in degrees (deg) in relation to backrest
angle and virtual origo point
C-46
n 300 Headrest communication status C-46
n.301 Headrest software major version C-47
n.302 Headrest software minor version C-47
n.303 Upgrade headrest software C-47
n.304 Headrest manual angle rotation speed Min = 0, Max = 15
Default = 6
Larger value is faster
C-47
n.305 Headrest manual height movement speed Min = 0, Max = 15
Default = 6
Larger value is faster
C-47
n.306 Headrest manual length movement speed Min = 0, Max = 15
Default = 10
Larger value is faster
C-47
n.307 Headrest automatic movement speed Min = 0, Max = 15
Default = 6
Larger value is faster
C-47
n.308 Headrest length current limit value Min = 0, Max = 15
Default = 11
Larger value = needs more cur-
rent (force) to stop
C-47
n.309 Headrest joint 2 closing gap stopping term value Min = 0, Max = 15
Default = 0
Larger value = stops less easy,
might be needed to increase
when using faster speeds
C-47
n.310 Headrest joint 2 (near cushion) ADC-value 528 -908 C-47
n.311 Headrest joint 1 (near backrest) ADC-value 85 - 477 C-47
n.312 Headrest length ADC-value 178 - 954 C-48
n 313 Headrest joint 2 (near cushion) drive WITHOUT limits
and potentiometer in Set mode
Displays text “H2- ” on the display
in Set mode
C-48
n 314 Headrest joint 1 (near backrest) drive WITHOUT limits
and potentiometer in Set mode
Displays text “H1- ” on the display
in Set mode
C-48
n 315 Headrest length calibration C-48
n 316 Headrest joystick directions and buttons C-48
n 317 Potentiometer select line test C-48
n.318 As service mode n.18 but only headrest endurance test For factory use. C-48
Table 11: Other service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
