PREVOST X3-45 Multiplex User Manual

Section 06: ELECTRICAL
PA1562
28
Problem/Symptom Probable Causes Actions
HVAC condenser fans not
functioning in speed 1
Circuit breaker CB7 was
manually tripped and not
reset
Check / reset circuit breaker CB7
HVAC condenser fans not
functioning in speed 2
Circuit breaker CB7 was
manually tripped and not
reset
Check / reset circuit breaker CB7
Windshield washer not
functioning
Windshield upper section
de-icing system not
functioning
Defroster fan is
functioning but no heat or
cooling available in the
driver area.
Module A46 is not powered
or is faulty
1. Check the SYSTEM DIAGNOSTIC
menu of the message center display
(MCD). Select FAULT DIAGNOSTIC
and ELECTRICAL SYSTEM. The
message “No Response ModA46,
Active” indicates a power problem on
the module. (A CAN network problem
would show the same message but
doesn't produce these symptoms).
2. Check / reset circuit breaker CB1
3. Check / replace fuse F12 or F13
4. Probe gray connector on module to
see if it is powered.
Low beam headlights and
front flasher on left side
not functioning
Electric horn not
functioning
Module A45 is not powered
or is faulty
1. Check the SYSTEM DIAGNOSTIC
menu of the message center display
(MCD). Select FAULT DIAGNOSTIC
and ELECTRICAL SYSTEM. The
message “No Response ModA45,
Active” indicates a power problem on
the module. (A CAN network problem
would show the same message but
doesn't produce these symptoms).
2. Check / reset circuit breaker CB2
3. Check / replace fuse F33 and F34
4. Probe gray connector on module to
see if it is powered.
Low beam headlights and
flasher on right side not
functioning
Module A48 is not powered
or is faulty
1. Check the SYSTEM DIAGNOSTIC
menu of the message center display
(MCD). Select FAULT DIAGNOSTIC
and ELECTRICAL SYSTEM. The
message “No Response ModA48,
Active” indicates a power problem on
the module. (A CAN network problem
would show the same message but
doesn't produce these symptoms).
2. Check / reset circuit breaker CB2
3. Check / replace fuse F33 and F34
4. Probe gray connector on module to
see if it is powered.
