34 PI-MAX/PI-MAX2 System Manual Version 5.F
 Timing Generator: a PTG (installed in the ST-133) or a Stanford Research
Systems DG535 Digital Delay/Pulse Generator with Inhibit Option and GPIB
cables.
*
 Detector-Controller cable:
PI-MAX: DB25 to DB25 cable. Standard length is 15 ft (6050-0336).
PI-MAX2: Cable set, 15 ft (6050-0499)
 Computer Interface: TAXI or USB 2.0.
 Computer: Can be purchased from Princeton Instruments or provided by user.
 WinView/WinSpec CD-ROM
 User Manuals
 Interface Dependent Components:
 Controller-Computer Interface cable:
 TAXI cable: DB9 to DB9 cable (6050-0148-CE is standard) or
 USB cable: Five (5) meter cable (6050-0494) is standard
 Interface Card: High Speed PCI Interface board for TAXI interface. USB 2.0
board for USB 2.0 interface is user-provided: native USB 2.0 support on the
motherboard or USB 2.0 Interface Card (Orange Micro 70USB90011
USB 2.0 PCI is recommended for desktop; SIIG, Inc. USB 2.0 PC Card,
Model US2246 for laptop).
 System Dependent Components
 PI-MAX to DG535 cable (6050-0385) and Filter (2550-0347)
 PI-MAX to PTG cable: Custom DB9 to DB9 cable (6050-0406, 15 ft/5 m is
standard)
 GPIB cables if a DG535 has been ordered
 Coolant Circulator and Coolant Tubing
If there are any problems, contact the Princeton Instruments Customer Support
department (see page 232 for contact information).
System Requirements
Environmental
Storage temperature 55°C
Operating environment temperature: 30°C > T > -25°C
Relative humidity <50% noncondensing...
Ventilation
Camera: Allow at least one-inch clearance for side and rear air vents.
*
Contact factory for information on how to install/enable the DG535 Inhibit function.
