PRÜFTECHNIK ROTALIGN Ultra iS User Manual

13
2.1.4 Component labelling
The labelling diagram below represents both sensALIGN sensor and sensALIGN laser.
The diagram shows the engraved symbols, markings and labels as they appear on the
respective measurement head. The laser safety labels are affixed on the housing of
sensALIGN laser at the positions shown in the diagram. The rechargeable battery label
is located on the rear of sensALIGN rechargeable battery.
Component labelling
Rechargeable lithium polymer battery
6Wh 3,7V 1,6Ah
T
range
= -10°C/14°F to 50°C/120°F
Charge only with battery charger ALI 4.651-I
between 0°C/32°F to 40°C/104°F
Aufladen nur mit Ladegerät ALI 4.651-I
im Bereich 0°C/32°F to 40°C/104°F
Caution
• Do not incinerate
• Do not disassemble
• Do not burn or expose to high temperature
• Do not short-circuit
• Dispose properly
Manufacturer:
PRÜFTECHNIK Alignment Systems GmbH
85737 Ismaning, Germany
www.pruftechnik.com
sensALIGN
™
LASER RADIATION
CLASS 2 LASER PRODUCT
IEC 60825-1:2007
P < 1mW, pulse < 400µs λ=635nm
Complies with 21 CFR 1040.10
and 1040.11 except for deviations
pursuant to Laser Notice No. 50,
dated June 24, 2007
DO NOT STARE
INTO BEAM
U
N
L
I
M
I
T
E
D
P
R
E
C
I
S
I
O
N
s
e
n
s
A
L
I
G
N
T
M
L
a
s
e
r
OPEN
LASER RADIATION
DO NOT STARE INTO BEAM
P < 1mW, pulse < 400µs λ=635nm
CLASS II LASER PRODUCT
AVOID EXPOSURE - Laser radiation
is emitted from this aperture
C A U T I O N
1
12
11
10
9
8
7
6
5
4
3
2
16
The black label is on the back of
sensALIGN rechargeable battery
ALI 4.960 which is mounted on
both sensALIGN laser ALI 4.910
and sensALIGN sensor ALI 4.900.
This label is found on
the side of sensALIGN
laser ALI 4.910.
The part number,
serial number and
date of manufacture
are engraved at
the bottom of both
sensALIGN sensor and
laser. The service and
calibration label is also
attached at the bottom
of the units.
This circular label is located
on the outside of the
sensALIGN laser aperture.
This label is found
on the side of
sensALIGN laser
ALI 4.910.
This symbol is engraved on the
top of both sensALIGN laser
and sensor, and indicates the
direction of the clamping levers
open position.
This symbol is engraved on the side of sensALIGN
sensor next to the countersunk hole, and indicates the
position to place the vibration check probe ALI 4.905
In this example, the next
calibration due date is May
2016.
