sensALIGN sensor and laser ‘ON/OFF/CHARGE’ workflow
Action sensALIGN laser status sensALIGN sensor status
With both laser and sensor OFF, press the ‘On/Off’
push button briefly
Laser turns ON Sensor turns ON and
measurement is POSSIBLE
Either laser or sensor connected to ROTALIGN
Ultra iS computer using the sensALIGN sensor
and laser cable ALI 4.921-2 ( applied when the
sensALIGN rechargeable battery ALI 4.960 has
a very low capacity or has been removed due to
clearance area restrictions)
Laser turns ON Sensor turns ON and
measurement is POSSIBLE
Either laser or sensor connected to mains supply
using sensALIGN charger/adapter ALI 4.651-I
with rechargeable battery ALI 4.960 attached
Laser switches to ‘charge’
mode and may be turned
on by pressing the ‘On/Off’
push button briefly
Sensor switches to ‘charge’
mode and measurement is
NOT possible. Measurement
may be reactivated by
pressing the ‘On/Off’ push
button briefly
Either laser or sensor connected to mains supply
using sensALIGN charger/adapter ALI 4.651-I
with rechargeable battery ALI 4.960 detached
Laser turns ON Sensor turns ON and
measurement is POSSIBLE
With both laser and sensor ON, press the ‘On/Off’
push button and hold down for a few seconds
Laser turns OFF Sensor turns OFF
