ROTALIGN Ultra iS Shaft handbook
210
sensALIGN laser
Type InGaAlP semiconductor laser
Beam divergence 0.3 mrad
Environmental protection IP 65 (dustproof and water jets resistant), shockproof
Relative humidity 10% to 90%
Beam power < 1mW
Wavelength (typical) 635 nm (red, highly visible)
Safety class and
Precautions
Class 2 according to IEC 608251-1; DO NOT star
e into laser beam
Temperature range Operation: -10°C to 50°C [14°F to 122°F]
Storage: -20°C to 60°C [-4°F to 140°F]
Charging: 0°C to 40°C [32°F to 104°F]
Dimensions Approx. 103 x 84 x 60 mm [4 1/32” x 3 5/16” x 2 3/8”]
Weight Approx. 330 g [11.6 oz]
Inclinometer resolution 0.1°
Inclinometer error ± 0.25% full scale
LED indicators 2 LEDs for battery status and laser transmission
Power supply Lithium Polymer rechargeable battery 3.7 V / 1.6 Ah 6 Wh
External mains supply
Operating time 70 hours continuous use [ Li-polymer battery]
Carrying case
Standar
d ABS, drop tested (2 m / 6 1/2 ft.)
Dimensions Case dimensions: approx. 565 x 375 x 193 mm [22 2/9” x 14 3/4” x 7 7/12”]
W
eight Including all standard parts: approx. 9 kg [19.8 lb]
