2.2.2 Computer LEDs
 The battery status LED blinks green during the battery recharging process,
staying steady green when battery is fully charged.
 The Bluetooth communication LED blinks blue while searching the neighbour-
hood for Bluetooth devices, staying steady blue when connected to the
sensALIGN sensor.
 The four alignment condition LEDs are used to indicate the position of the laser
beam on the detector during beam adjustment, and the actual alignment status
after measurement.
LED Laser beam adjustment Alignment status
Blue Laser beam centred Excellent
Green Laser beam OK Acceptable
Amber Laser beam out of recommended
measurement part of detector
Bad
Red Laser beam off Grossly misaligned
2.2.3 Power supply
ROTALIGN Ultra iS is powered using a 7.2 V 6.0 Ah Lithium-ion rechargeable battery
ALI 4.603, which is to be charged only using the battery charger ALI 12.651-I. This
can be done with the battery inside the computer. The computer may continue to be
used if the battery is charged inside it.
Alternatively, use 6 standard ‘C’ size [IEC LR 14] batteries contained in the optional
battery compartment ALI 4.605.
If the ROTALIGN Ultra iS computer is not in use for extended periods of time,
a month or more, the rechargeable battery or the standard batteries should be
removed from the unit.

CAUTION
I
f
the ROTALIGN Ultra iS computer is not in use
f
or extended periods o
f
time,
a
month or more, the rechar
g
eable batter
y
or the standard batteries should be
r
e
m
o
v
ed
fr
o
m
t
h
e
u
ni
t
.
