Appendix
209
ROTALIGN Ultra iS technical data
ROTALIGN Ultra iS computer
CPU Intel XScale
®
Processor 520 MHz
Memory 64 MB RAM, 64 MB Internal Flash,1024 MB Compact Flash Memory
Display Type: Transmissive (sunlight-readable) backlit TFT colour graphic display
Resolution: Full VGA, 640 x 480 Pixel
Dimensions: 5.7 inch (145 mm) diagonal
Keyboard elements: Navigation cursor cross with up, clear and menu
keys; Alphanumeric keyboard with dimensions, measure and results hard
keys
LED indicators 4 LEDs for laser status and alignment condition
2 LEDs for wireless communication and battery status
Power supply Operating time: 25 hours (using Li-Ion rechargeable battery) 12 hours
(using disposable batteries) typical use (based upon an operating cycle of
25% measurement, 25% computation and 50% ‘sleep’ mode)
Disposable batteries: 6 x 1.5 V IEC LR14 (“C“) [optional]
Lithium-Ion rechargeable battery: 7.2 V / 6.0 Ah
External interface 2 x USB host for printer, keyboard, USB stick
1 x USB slave for PC communication
RS-232 (serial) for sensor
RS-485 (serial) for sensor
I-Data socket for sensor
Ethernet
Integrated wireless communication, class 1, transmitting power 100 mW
AC adapter/charger socket
Environmental protection IP 65 (dustproof and water jets resistant), shockproof
Relative humidity 10% to 90%
Temperature range Operation: 0°C to 45°C [32°F to 113°F]
Storage: -20°C to 60°C [-4°F to 140°F]
Dimensions Approx. 243 x 172 x 61 mm [9 9/16” x 6 3/4” x 2 3/8”]
Weight 1 kg / 2.2 lbs (without battery)
CE conformity Refer to the attached CE compliance certificate attached in the appendix
sensALIGN sensor
CPU and memory ARM Cortex™ M3 and 2GB Flash memory
Environmental protection IP 65 (dustproof and water jets resistant), shockproof
Relative humidity 10% to 90%
Ambient light protection Optical and active electronic digital compensation
Temperature range Operation: -10°C to 50°C [14°F to 122°F]
Storage: -20°C to 60°C [-4°F to 140°F]
Charging: 0°C to 40°C [32°F to 104°F]
Dimensions Approx. 103 x 84 x 60 mm [4 1/32” x 3 5/16” x 2 3/8”]
Weight Approx. 310 g [10.9 oz]
Measurement range Unlimited, dynamically extendible (US. Patent 6,040,903)
Measurement resolution 1 µm
Measurement error < 1.0%
Inclinometer resolution 0.1°
Inclinometer error ± 0.25% full scale
Vibration measurement mm/s, RMS, 10Hz to 1kHz, 0 mm/s – 5000/f • mm/s² (f in Hertz [1/s])
External interface Integrated Bluetooth
®
Class 1 wireless communication, RS232, RS485,
I-Data
LED indicators 4 LEDs for laser adjustment, 2 LEDs for Bluetooth
®
communication and
battery status
Power supply Lithium Polymer rechargeable battery 3.7 V / 1.6 Ah 6 Wh
Operating time 12 hours continuous use
