PRÜFTECHNIK ROTALIGN Ultra iS User Manual

189
This customization option is very important in that it determines how a user
navigates through the system. It would be advisable to try out the different
options to establish which option suits you best. In this operating instruction we
will try to stay with the option ‘Editing moves focus’.
Word completion
Two options are available – ‘Enabled’ or ‘Disenabled’
User viewable files
Two options are available – ‘Only user files and templates’ or ‘All files from all users’
8.1.12 Measurement file backup
As an extra data storage capability, ROTALIGN Ultra iS Shaft measurement files may
be saved and stored on memory devices such as memory sticks (aka jump drives) or
on PCs.
The configuration item ‘Backup user files’ is used to create a backup file of all
measurement files on any particular ROTALIGN Ultra iS computer.
Attach an approved memory stick to the USB/peripheral devices cable ALI 12.503
(short USB cable) then connect the USB cable to the ROTALIGN Ultra iS computer USB
port ( refer to figure below).
Highlight ‘Backup user files’ icon then confirm selection by pressing
e. The following
hint appears.
Use
i/h to highlight ‘Yes’ then press e to confirm selection.
Th
is customization option is very important in t
h
at it
d
etermines
h
ow a user
n
avigates through the system. It would be advisable to try out the di
ff
erent
o
ptions to establish which option suits you best. In this operating instruction we
w
ill tr
y
to sta
y
with the option ‘Editin
g
moves focus’.
Note
USB/peripheral device cable
ALI 12.503 (short USB cable
Approved USB stick ( aka
jump drive)
The USB/peripheral
devices cable ALI 12.503
may be inserted in either
of the two USB interfaces
Restoring files
